CasterBot 2.4 inch 60mm Mecanum Wheels Load Capacity 10kg include TT/Servo Motor Coupling Compatible for LEGO/TT Motor/DC Motor/Servo Motor
This set of mecanum wheels includes 2 left wheels and 2 right wheels. It is a LE GO compatible mecanum wheel, it comes with an our compatible coupling and an axle centre hub for the arduino motors and wheels. You can also use universal coupling to connect the wheels and motor. It will give you more choice, each wheel is comprised of 8 rubber rollers, these axles and rollers are sandwiched between two aluminum plates, use these mecanum wheels on your robot, it can be able to forward/backward movement, but also side to sie.Using rollers set on 45 degree rotational axis parallel to the mai rotational axis of the wheel, all of you need to do is to add your drive motors, controller boars and batteries.
This is a compact structure, flexible movement and durable in use omnidirectional Mecanum wheel for all types of smart robot cars. Compared to other common wheels, this Mecanum wheel can allow your car to achieve 360° movement for faster travel in a variety of environmental terrains. It defaults to the cross-axis mounting port, which can be plugged into the building block servo and building block motor, making it easy to build an Omni-directional mobile smart building block car. Four mounting adapters will be provided for connection to TT motors. Make four-wheel-drive smart car realize left and right translation, large-angle drift, oblique 45° direction movement, square track movement and other movement modes.
60mm Mecanum Wheels Specifications:
Number of Rollers:8 pcs
Number of Plates: 2 pcs
Number of bearing: 16 pcs
Body Material:Aluminum Alloy
Roller Material: PP+PE
Length of Roller:30mm
Net weight: 86g x4
Load Capacity: 10kg
60mm Mecanum Wheels Packing List:
2 x Right Mecanum Wheels
2 x Left Mecanum Wheels
4 x Plastic cross axle coupling(used to be connected with TT Motor)
4 x Plastic axle center coupling(used to be connected with servo motor)
12 x Hexagon Socket Head Cap Screw M3*40mm.
